NASN POWER offers advanced smart Forklift Battery Fast Charger in 24 volt, 48 volt, 72 volt, 96 volt, and customized voltage 200 volt, suitable for various material batteries cycle working charging.
FEATURES
Opportunity Charging
Keep the battery charged just enough with the sporadic charges to keep things going through the shifts.
Battery protection technology
Advanced monitor, manage, protect battery & extend its life.
HIGH efficiency
Industrial charger with 95% energy efficiency and lowest monthly utility cost. Energy savings.
Electronic Protection
Over/Under Voltage/Current/
Temperature protection, short circuit protection,surge protection.
OCPP compliant
Based on WIFI/4G, with OCPP protocol, allow remote control including start,stop and billing records,etc.
User-friendly LCD interface
Touch screen operation,showing charging voltage,current,
charged time,temperature,etc.
Super background setting.
Specification
Item | Content | NEC-144 | NEC-200 |
AC input | Input Type | Three phase | |
Rated Voltage | 325-456V | ||
Rated Current | 10A | 30A | |
DC output | Output Voltage | 108-180V | 0-200V |
Maximum Current | 50A | 150A/200A | |
Rated Power | 7kW | 20kW | |
User Interface | Charge Connector | GB/T Plug | GB/T Plug |
Cable Length | 5m or Customized | ||
LCD Display | 4.3-inch | ||
RFID Reader | MifareISO/IEC14443A | ||
Start Mode | Plug&Charge/RFID Card | ||
Communication | Protocol | GBT27930/CHADEMO2.0/DIN70121 | |
Backend | Wi-Fi /4G | ||
Charging protocol | OCPP-1.6J | ||
Safety | Ingress Protection | IP55 | |
Impact Protection | IK10 | ||
Electrical Protection | Over/Under Voltage Protection,Over Current Protection, Short Circuit protection, Over/Under Temperature Protection,Surge protection | ||
Environment | Installation | Wall-mount/Pole-mount(Optional) | |
Operate Temperature | -30℃ ~ +50℃ | ||
Operate Humidity | 95%,Non-condensing | ||
Operate Altitude | <2000m |
